Main Features
199 Memory Channels
With LCD Display
Wire Clone
PC Programming
CTCSS 50 Groups, DCS 83*2 Groups
Hand free VOX
Sound Alert
Calling Remind
Group Function
Emergency call function
Specifications
| General |
| Frequency Range | VHF:136~174MHZ |
| Channel NO. | 199 |
| CTCSS/DCS | 50 group CTCSS;83*2 group DCS |
| Working Voltage | 7.4V(LI-ION Battery) |
| Working Temperature | –100°c~+ 60°c |
| Antenna Impedance | 50 Ω |
| Ground Method | Negative Pole |
| Work Mode | Simplex |
| Transmitter | |
| Power Output | 5W |
| Modulation Mode | FM |
| Remanent Radiation | <-60dB |
| Emission Current | ≤0.8A |
| Modulation Limit | ≤+5KHz |
| Modulation Sensitivity | 2~20mV |
| Frequency Stability | ±5ppm |
| Receiver | |
| Sensitivity | 0.20µV |
| Audio Respond | 300~3000Hz |
| Audio Power | ≥0.5W |
| Audio Distortion | ≥10% |
| Bandwidth | ≤16KHz |
